- Patch Panel UTP 24 ports RJ45 cat. 6
- solid and resistant terminations for copper cabling featuring connectors with gold contacts of 3micro-inches
- Compatible with both 110 and Krone inserter
- Supports rigid and flexible cable 22 to 26 AWG
- For use with unshielded twisted-pair network cable (UTP) Cat6
- The Cat6 performance is compliant with ANSI / TIA / EIA 568 B.2-1
- Ideal for Ethernet applications, Fast Ethernet and Gigabit Ethernet
- Connects RJ-45 ports to the network
- Meets 19 “rackmount
Standard
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
- IEEE 802.3ab (1000Base-T Gigabit Ethernet)
Certifications
- RoHS
- WEEE
Physical characteristics
- Dimensions: 482 mm (L) x 43 mm (H) x 48 mm (D)
- Horizontal distance between left and right mounting holes: 465 mm
- The vertical distance between the mounting holes in the top and bottom: 31.8 mm
- Operating temperature: -40 – 68 ° C
Package Contents
- Patch Panel
- 4 mounting screws
- Quick Install GuideStandard
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3u (100Base-TX Fast Ethernet)
- IEEE 802.3ab (1000Base-T Gigabit Ethernet)
Certifications
- RoHS
- WEEE
Physical characteristics
- Dimensions: 482 mm (L) x 43 mm (H) x 48 mm (D)
- Horizontal distance between left and right mounting holes: 465 mm
- The vertical distance between the mounting holes in the top and bottom: 31.8 mm
- Operating temperature: -40 – 68 ° C
Package Contents
- Patch Panel
- 4 mounting screws
- Quick Install Guide
